UTR 9000
Durable and High-Strength SLA Resin
UTR 9000, a specialized SLA resin from UnionTech, excels in delivering high-detail and durable parts, ideal for prototyping applications requiring impact strength.
SLA (Stereolithography)Photopolymer Resins
Technical Specifications
Download DatasheetWhite
355 Cps (28 °C)
1.13 g/cm³ (25 °C)
9.3 mJ/cm²
0.145 mm
0.1 mm
27–31 MPa (ASTM D638)
2,189–2,395 MPa (ASTM D638)
12–20% (ASTM D638)
69–74 MPa (ASTM D790)
2,692–2,775 MPa (ASTM D790)
58–70 J/m (ASTM D256)
83 (ASTM D2240)
52 °C (ASTM D648, 66 Psi)
62 °C (DMA, E″ Peak)
97 × 10⁻⁶ /°C (TMA, T < Tg)
1.16 g/cm³
Lite600, Lite600 2.0, Lite800, Pilot250, Pilot450, RSPro600 2.0, RSPro800 2.0, RSPro800 X, RSPro1400, RSPro1800, RSPro2100
It can also be used with third-party systems that meet the material requirements, in addition to the listed systems. Parameters must be developed separately.
Key Features and Applications
Key Features
- Offers low shrinkage and good resistance to yellowing.
- Provides a glossy white appearance.
- Shows long in-machine service life and superior machinability.
Applications
- Ideal for master models and concept models in automotive, medical and consumer electronics.
- High-quality control in vacuum casting parts.
