Temp R220
High-Temperature SLA Resin
Temp R220 is a UV-curable resin developed for industrial SLA printing, producing parts with high temperature resistance. It offers a heat deflection temperature (HDT) of up to 227 °C at 0.455 MPa, ensuring stable performance under demanding thermal conditions.
Technical Specifications
Download DatasheetTransparent Amber Liquid
518 Cps (30 °C)
1.18 g/cm³ (25 °C)
17.46 mJ/cm²
0.1316 mm
120.3 mJ/cm²
129 MPa (ASTM D790)
4,300 MPa (ASTM D790)
26 J/m (ASTM D256)
90 (ASTM D2240)
227.5 °C (ASTM D648)
After cleaning and drying, heat treat at 120–200 °C for 4 h.
Lite600, Lite600 2.0, Lite800, Pilot250, Pilot450, RSPro600 2.0, RSPro800 2.0, RSPro800 X, RSPro1400, RSPro1800, RSPro2100
It can also be used with third-party systems that meet the material requirements, in addition to the listed systems. Parameters must be developed separately.
Key Features and Applications
Key Features
- Offers heat resistance up to 227 °C.
- Provides stable printing and simple post-processing.
- Shows high flexural strength and hardness.
Applications
- Ideal for wind tunnel models, impellers and engine parts.
- Rapid tooling production.
