Crysta-EB
Investment Casting Patterns in Hours
Crysta-EB is a clear SLA resin specifically developed for creating investment casting patterns. It delivers optimal thermal expansion, supports complex geometries, and leaves minimal ash residue, making it ideal for high-precision casting applications.
Technical Specifications
Download DatasheetTransparent
310–410 Cps (25 °C)
1.12 g/cm³ (25 °C)
9.7 mJ/cm²
0.18 mm
0.1 mm
44–62 MPa (ASTM D638)
2,590–2,760 MPa (ASTM D638)
7–11% (ASTM D638)
75–84 MPa (ASTM D790)
2,680–2,880 MPa (ASTM D790)
28–38 J/m (ASTM D256)
83 (ASTM D2240)
40–51 °C (ASTM D648, 66 Psi)
42–58 °C (DMA, E″ Peak)
≤ 0.04%
Lite600, Lite600 2.0, Lite800, Pilot250, Pilot450, RSPro600 2.0, RSPro800 2.0, RSPro800 X, RSPro1400, RSPro1800, RSPro2100
It can also be used with third-party systems that meet the material requirements, in addition to the listed systems. Parameters must be developed separately.
Key Features and Applications
Key Features
- Offers superior clarity and excellent accuracy.
- Good green strength requires minimal post-processing.
- Burns out completely and is suitable for casting.
Applications
- Ideal for producing master models for precision casting.
- Transparent prototypes in automotive, medical and consumer electronics.
