FLIGHT® 403P-2 Series
2-Laser Upgrade to FLIGHT® 403P Series
FLIGHT® 403P-2 Series enhances the original 403P platform with 2 fiber lasers, boosting throughput. With a 400 × 400 × 540 mm build volume and open platform, it’s built for high-speed industrial production.
Browse Farsoon 3D printers.
The products below are optional but included in the quote for successful operation.
Equipment: MCWI-15C Chiller, FS-EC-01P External Cooling Station, FS04-PPS Powder Cleaning Station, FS-PMS-02P Powder Management System, FS-M-50 Powder Mixer, ATTIX 961-01 Industrial Vacuum Cleaner, HC-9060A Sandblasting Machine, HSFD39-5 Nitrogen Generator, LG-10 Air Compressor, DHG-9123AS Powder Drying Oven
Technical Specifications
Download DatasheetSLS (Selective Laser Sintering)
400 × 400 × 540 mm
2 × 300 W Maxphotonics Fiber Laser
High-Precision 3-Axis Galvanometer System
≤ 20 m/s
FLIGHT® SS403P-H-2: 190 °C
FLIGHT® HT403P-H-2: 220 °C
0.06–0.30 mm
Nitrogen
Eight-Zone Heater and Intelligent Temperature Control Systems
Real-Time, Continuous Monitoring and Optimization of the Build Surface Temperature
Windows 11 (64-Bit)
BuildStar, MakeStar®: Open Access to Core Machine Parameters, Real-Time Changes to Build Parameters, 3D Visualization and Fault Diagnostics
STL
2,540 × 1,370 × 2,225 mm
~ 3,000 kg
400 V ±10%, 3~/N/PE, 50/60 Hz, 32 A
22–28 °C
CE
FLIGHT® SS403P-H-2: FS3150CF (PA12-CF), FS3201PA-F (PA12), FS3300PA-F (PA12), FS3401GB-F (PA12-GB)
FLIGHT® HT403P-H-2: FS3150CF (PA12-CF), FS6140GF (PA6-GF), FS3201PA-F (PA12), FS3300PA-F (PA12), FS3401GB-F (PA12-GB), FS6130CF-F (PA6-CF)
The system is an open platform; besides the listed materials, it is also compatible with third-party materials that the machine specifications support. Parameters must be developed separately.
Double Capacity in the Same Footprint
2 x 300 W fiber lasers: twice the scanning capacity in the same 403P footprint, designed for high-volume series production.
High-Volume Production
The 2 lasers share the build area, lowering cost per part and shortening lead times.
Design Freedom
Polyamide lattice structures, integrated assemblies and lightweighted geometries are produced as a single part.
Large Build Volume
400 × 400 × 540 Mm, for large parts or densely nested batches of small parts.
Bobsled Helmet Liner
Developed for a bobsled team at the 2022 Winter Olympics. The lattice design is tailored to each athlete using 3D scan data; the 2-laser system produces two helmet liners in a single build.
- Material
- WF-PU95AB (TPU)
- System
- FLIGHT® HT403P-2
- Print Time
- 7.5 Hours • 2 Parts
System Workflow
-
Data Preparation
The build is laid out in BuildStar.
-
Cartridge Loading
Powder is filled into the feed cartridge.
-
3D Printing
Parts are built layer by layer with the laser.
-
Cartridge Change
The cartridge cools outside the machine.
-
Depowdering
Parts are removed at the station.
-
Post-Processing
Sandblasting and surface finishing are applied.
