FS6130CF-F
Carbon Fiber PA6 for FLIGHT®
FS6130CF-F is a carbon fiber-reinforced PA6 SLS powder developed for FLIGHT® systems, offering high tensile strength and thermal resistance. Its low refresh rate enables efficient, high-performance part production.
SLS (Selective Laser Sintering)Polymer Powders
Technical Specifications
Download Datasheet0.5 g/cm³
1.07 g/cm³
Black
222.5 °C (ISO 11357-1:2020)
210 °C (ISO 78-1:2020)
214 °C (ISO 78-1:2020)
110 MPa (ISO 527-1:2019)
10,000 MPa (ISO 527-1:2019)
2.5 % (ISO 527-1:2018)
135 MPa (ISO 178:2019)
6,000 MPa (ISO 178:2019)
4 kJ/m² (ISO 180:2019)
25 kJ/m² (ISO 180:2019)
FLIGHT® HT252P, FLIGHT® ST252P, FLIGHT® HT403P-H, FLIGHT® HT403P-H-2, FLIGHT® HT601P-4, FLIGHT® HT1001P-4
The material can also be used with third-party systems that meet its requirements, in addition to the listed systems. Parameters must be developed separately.
Key Features and Applications
Key Features
- Delivers excellent tensile strength, modulus and corrosion resistance.
- Provides outstanding high-temperature performance.
- Shows good wear resistance.
Applications
- Ideal for functional verification and small-scale production; an alternative to CNC machining and injection molding.
- End-use parts for high-temperature environments in automotive and electronics.
