HBD Hastelloy X Superalloy
Developed for Extreme Conditions
Hastelloy X is a nickel-based superalloy designed for high-temperature environments, offering excellent oxidation and corrosion resistance. It is commonly used in aerospace, gas turbines, and industrial furnaces, known for its durability and formability under extreme conditions.
Technical Specifications
Download DatasheetNi (Balance), Cr 20.5–23.0, Fe 17.0–20.0, Mo 8.0–10.0, Co 0.5–2.4, W 0.2–1.0, Si ≤ 1.0, Mn ≤ 1.0 (GB/T 14992-2005)
15–53 µm (GB/T 19077-2016)
~ 8.2 g/cm³ (GB/T 3850-2015)
> 99.9% (GB/T 3850-2015)
≥ 6 µm (GB/T 40389-2021)
590 ± 100 MPa (GB/T 228.1-2015)
750 ± 120 MPa (GB/T 228.1-2015)
34 ± 12 % (GB/T 228.1-2015)
330 ± 50 MPa (GB/T 228.1-2015)
710 ± 50 MPa (GB/T 228.1-2015)
45 ± 6 % (GB/T 228.1-2015)
30 Minutes at 600 °C, 70 Minutes at 1,170 °C, Air Cooling
HBD 150, HBD 200, HBD 200Pro, HBD 400, HBD 500, HBD 600, HBD 800, HBD 1600
Besides the listed systems, the material can also be used with third-party systems that meet its requirements. Parameters must be developed separately.
Key Features and Applications
Key Features
- Provides excellent oxidation resistance at high temperature.
- Offers good formability and weldability.
- Is used in hot-section gas turbine parts.
Applications
- Gas turbine combustion chambers and transition ducts.
- Industrial furnace components and heat treatment fixtures.
