HBD 316L Stainless Steel
Versatile Corrosion-Resistant Alloy
316L stainless steel 3D printing powder is widely preferred for its exceptional corrosion resistance and versatility across various industries.
Technical Specifications
Download DatasheetFe (Balance), Cr 16.0–18.0, Ni 10.0–14.0, Mo 2.0–3.0, Mn ≤ 2.0, Si ≤ 1.0 (GB/T 20878-2007)
15–53 µm (GB/T 19077-2016)
~ 7.9 g/cm³ (GB/T 3850-2015)
> 99.9% (GB/T 3850-2015)
≥ 6 µm (GB/T 40389-2021)
510 ± 100 MPa (GB/T 228.1-2015)
700 ± 100 MPa (GB/T 228.1-2015)
35 ± 10 % (GB/T 228.1-2015)
93 ± 3 HRB (GB/T 230.1-2018)
520 ± 100 MPa (GB/T 228.1-2015)
720 ± 100 MPa (GB/T 228.1-2015)
32 ± 10 % (GB/T 228.1-2015)
93 ± 3 HRB (GB/T 230.1-2018)
2 Hours at 800 °C, Furnace Cooling
HBD 150, HBD 200, HBD 200Pro, HBD 400, HBD 500, HBD 600, HBD 800, HBD 1600
Besides the listed systems, the material can also be used with third-party systems that meet its requirements. Parameters must be developed separately.
Key Features and Applications
Key Features
- Provides excellent corrosion resistance.
- Suits a wide range of applications.
- Shows high ductility as built.
Applications
- Pore-free breathable shoe molds and rubber sole molds.
- Turbine engine exhaust nozzles.
