Intamsys INTAM™ PC-PBT 3D Printing Material

Intamsys

INTAM™ PC-PBT

Name: INTAM™ PC-PBT
Brand: Intamsys

Cold-Tough PC-PBT

PC-PBT combines low-temperature impact toughness with chemical and heat resistance. A reliable choice for functional parts exposed to cold or harsh environments.

FFF (Fused Filament Fabrication)Thermoplastic Filaments

Color: Black

Weight:

Product variants:

Get a Quote

Technical Specifications

Download Datasheet

1.2 g/cm³ (ISO 1183)

140 °C (DSC, 10 °C/min)

223 °C (DSC, 10 °C/min)

91 °C (ISO 75)

16–22 g/10 min (260 °C, 5 kg)

43.2 MPa (ISO 527)

2,100 MPa (ISO 527)

6.9% (ISO 527)

56.7 MPa (ISO 178)

1,938 MPa (ISO 178)

26.9 kJ/m² (ISO 179, Notched)

FUNMAT HT, FUNMAT PRO 310 NEO, FUNMAT PRO 310 APOLLO, FUNMAT PRO 410, FUNMAT PRO 610HT

Can also be used with third-party systems that meet the material requirements, in addition to the listed systems. Parameters must be developed separately.

Key Features and Applications

Key Features

Offers good heat resistance.
Retains toughness at -20 / -30 °C.
Shows good chemical resistance.

Applications

Ideal for automotive parts operating at low temperatures.
Functional components exposed to chemicals.

Compatible Systems

Can also be used with third-party systems that meet the material requirements, in addition to the listed systems. Parameters must be developed separately.

Typical values are for reference and comparison only and must not be used for design specifications or quality control. Actual values may vary with printing conditions. Test specimens were produced under laboratory conditions on FUNMAT 3D printers with 100% infill.
