INTAM™ PA12-CF
Tough and Thermally Stable
PA12-CF is a carbon fiber-reinforced Nylon 12 filament known for its low moisture absorption and excellent strength retention. Delivers stable mechanical and thermal performance in challenging environments.
FFF (Fused Filament Fabrication)Thermoplastic Filaments
Technical Specifications
Download Datasheet1.06 g/cm³ (ISO 1183)
108 °C (DSC, 10 °C/min)
165 °C (DSC, 10 °C/min)
105 °C (ISO 75)
25 g/10 min (280 °C, 2.16 kg)
69.3 MPa (ISO 527)
3,748 MPa (ISO 527)
2.9% (ISO 527)
114.1 MPa (ISO 178)
3,532 MPa (ISO 178)
12.1 kJ/m² (ISO 179, Notched)
FUNMAT HT, FUNMAT PRO 310 NEO, FUNMAT PRO 310 APOLLO, FUNMAT PRO 410, FUNMAT PRO 610HT
Can also be used with third-party systems that meet the material requirements, in addition to the listed systems. Parameters must be developed separately.
Key Features and Applications
Key Features
- Offers low moisture sensitivity.
- Retains superior mechanical and thermal properties even after moisture conditioning.
- Provides high strength and stiffness through carbon fiber.
Applications
- Ideal for functional parts operating in humid environments.
- Aerospace, automotive, and industrial jigs and fixtures.
